Hikvision DS-1LN6USL5 305 Meter CAT6 LSZH UTP Cable

Specification of the Hikvision DS-1LN6USL5 305 Meter CAT6 LSZH UTP Cable Brand Hikvision Model DS‑1LN6USL5 Length 305 ± 1.5 m Category Cat 6 (U/UTP) Conductor Material Solid bare copper (99.95%) Conductor Diameter 0.565 ± 0.005 mm (≈ 23 AWG) Insulation Material HDPE Insulation Diameter 0.98 ± 0.05 mm Structure 4 twisted pairs (U/UTP) Sheath Material LSZH (Low Smoke Zero Halogen) Fire‑resistance / Certification CPR Eca Usage Scenario Indoor structured cabling Sheath Colour White Rip‑cord Yes Separator Yes Resistance to Cold Bend –20 ± 2 °C × 4h, 8× cable O.D., no visible cracks Impedance 100 ± 15 Ω @ ≤ 100 MHz; 100 ± 25 Ω @ 100‑250 MHz Delay Skew ≤ 45 ns/100 m DC Resistance ≤ 9.38 Ω/100 m DC Conductor Resistance Unbalance ≤ 5.0% Standards Compliance ANSI/TIA‑568.2‑D, IEC 61156, ISO/IEC 11801, RoHS 2.0 Operating Temperature ‑20 °C to 75 °C Upon Aging Tensile Strength Tensile strength ≥ 8.0 MPa; Elongation ≥ 100% (after aging) Hikvision DS-1LN6USL5 305 Meter CAT6 LSZH UTP Cable The Hikvision DS-1LN6USL5 305 Meter CAT6 LSZH UTP Cable is a high-performance network cable designed for reliable and efficient data transmission in modern structured cabling systems. Engineered to meet Cat6 standards, this cable supports high-speed networking applications, ensuring stable connectivity for IP cameras, computers, switches, and other network devices over long distances.   Constructed with solid bare copper conductors, the cable provides excellent electrical conductivity and minimal signal loss. Each of the four twisted pairs is insulated with HDPE material, maintaining signal integrity while reducing interference and crosstalk. The Low Smoke Zero Halogen (LSZH) sheath ensures safety by producing minimal smoke and no toxic gases in the event of a fire, making it ideal for indoor installations in offices, schools, hospitals, and other public spaces.   The DS-1LN6USL5 cable is designed for durability, with a rip-cord and internal separator to simplify installation and maintain consistent pair spacing. Its resistance to cold bend and high tensile strength ensures long-term reliability even in challenging environmental conditions. With full compliance to ANSI/TIA, ISO/IEC, and IEC standards, this cable guarantees quality performance and safety.   What is the price of the Hikvision DS-1LN6USL5 305 Meter CAT6 LSZH UTP Cable in Bangladesh? The latest price of the Hikvision DS-1LN6USL5 305 Meter CAT6 LSZH UTP Cable in Bangladesh is 17,900 BDT. You can buy the Hikvision DS-1LN6USL5 305 Meter CAT6 LSZH UTP Cable us at the best price. You can either buy it through our website or directly visit our office. Our Office Address: 51, Kazi Villa, 3rd Floor, Suvastu Arcade ICT Bhaban Goli, New Elephant Road, Dhaka-1205, Bangladesh. Contact Us: 88 01894-68343
